PM100

INTELLI-RV PRODUCTS

Projecta’s Intelli-RV range offers a comprehensive power management system solution to suit caravans and recreational vehicles, providing easier, safer installation and battery/solar management. Within the range are four different kits offering customers a variety of features and components to suit their application and budget. Designed with ‘plug and play’ in mind, to complete wiring installation you only need a screwdriver and the necessary DC cables.

PM100


PM100

0.00

The entry level system for set-and-forget battery system management. Includes centralised unit for neat and easy wiring of lighting and electricals, 35A power supply, 5 stage charging via DC 100A VSR* or 20A charge via AC plug.

PM100 connects your service/caravan battery to the vehicle starter battery and ensures alternator charge prioritises the starter battery first. It protects the voltage of the starter battery so you can start your car every single time, even with a heavy load on the auxiliary. Features 10 channel fused output via screw terminals, L.E.D status indicators and charge or power supple switch.

*100A for 30mins 60A continuous

DOWNLOADS

Instruction Manual

Brochure

Add To Cart


FEATURES

Voltage Sensitive Relay engages & disengages with engine

Voltage Sensitive Relay engages & disengages with engine

20A Charger, 35A Power Supply

20A Charger, 35A Power Supply

Screw terminals for input and output

Screw terminals for input and output

Charge or Power Supply Switch

Charge or Power Supply Switch

LVD to protect the battery from deep discharge

LVD to protect the battery from deep discharge



COMMON ACCESSORIES

PMTEX-2 - 2m Extension Cable for Temperature Sensor

PMTEX-4 - 4m Extension Cable for Temperature Sensor

PMAC - AC Power Cord, 1.5m

PMBS - Battery Sensor with 3m of Cable

PMBEX-2 - 2m Extension Cable for Battery Sensor

PMBEX-4 - 4m Extension Cable for Battery Sensor

PMLCDC - 5m Cable to suit LCD Screen (Crystal Display)

PMSWEX-2 - 2m Extension Cable for Panel Switch, LED and LCD Monitor

PMSWEX-4 - 4m Extension Cable for Panel Switch, LED and LCD Monitor

PMWS200 - 200mm Water Sensor with 4m Cable

PMWS400 - 400mm Water Sensor with 4m Cable

PMWEX-4 - 4m Extension Cable for Water Sensor

COMPONENTS

PM100 - 12V 20A Charger & 35 Amp Power Supply

SPECIFICATIONS

12V A Charger

35A Power Supply

100A DC VSR

10 Fused Outputs

WIRING UNIT DIMENSIONS

273mm long

197mm wide

70mm high
